ALD-ST3-450 5D solder paste inspection machine offers full inspection coverage and 3D measurement of all types of paste deposits down to 01005 and micro-BGA pads. Supports high-speed SMT lines, with a 3 FOV/sec. rate (FOV size is 30.72mm x 30.72mm). Automatic operations. Closed-loop feedback and user alert system. Connects to central database. Bidirectional light projection eliminates shadow effects. Calculates and compensates for PCB warpage. Insensitive to color. Resolution: 15 microns. Volume accuracy is <1% at 3 Sigma.
ALeader, www.aleader-europe.com
S-1200-LV places LED components and other regular- and irregular-shaped components ranging from 0603 to 7474. Handles LED boards up to 4' long. Placement speed 28,000 cph.
Shenzhen Southern Machinery, www.smthelp.com
ALD oxide nanolaminates efficiently protect printed circuit board components from aging effects such as corrosion and tin whisker formation. Forms ultra-thin, hermetic, inert, flexible, and protective film over whole board, isolating even the most sensitive points from the ambient conditions. Due to the nanometer-scale thickness, has negligible impact on PCB functionality.
Picosun Oy, www.picosun.com
Argomax 9000 silver sintering preforms reportedly deliver superior thermal conductivity, ultra-high reliability and excellent electrical conductivity. These die attach materials can be used from power modules to automotive applications. Come in tape-and-reel format and waffle pack for standard pick-and-place equipment.
Alpha Assembly Solutions, www.alpha.alent.com
K5000 manual and autoload depanelizer singulates multiple pre-scored printed circuit board panels in one pass. Panels up to 10.6" wide can be separated by placing onto an input conveyor to be passed onto separator blades. Comes in four configurations: as standalone straight-through operator load/unload machine, as an inline microprocessor-controlled SMEMA interface system for PCB hand-off from reflow output conveyor, as a single operator side-load system for LED lighting strips, and in an automatic PCB Rack input version for batch processing. Cutting area protected by see-through cover. Separated panels slide down an incline onto a conveyor belt or take-up tray. Up to 14 sets of blades can be placed side by side onto separator mandrels for singulating strips as thin as 0.5". Changing blade sets for different PCB panels is done from the side of the machine and takes about 15 min.
FKN Systek, www.fknsystek.com
F7000SR desktop soldering robots reportedly have high repeatability. Can replace hand soldering applications or bring outsourced applications in-house. Include built-in solder tip cleaning station. Designed to handle solder diameters ranging from 0.6 to 1.2mm and have adjustable temperature control.
Fisnar, www.fisnar.com
