vVision 2.4 software platform optimizes inspection program creation, especially for new components and special component types, and comprehensive 3D advancements such as 3D solder joint inspection for chips.

Speeds switches between existing inspection programs and development of new inspection programs. Novel inspection pattern tool for NPI (New Product Introduction) uses existing libraries as well as AOI 3D technology to automatically assign components in the new layout to existing inspection patterns. In addition to an evaluated defect image in the center, optional good and bad examples are presented for comparison to aid decision. The defect site and additional information can be displayed on a second monitor or with the shift key. To support traceability, screenshots and 3D images can be directly saved at any time so they can be logged and used in quality reports. New OCR recognition uses intelligent algorithms to ensure automatic reading and reliable evaluation.

Viscom

viscom.com
